HZ2Y Porous sintered copper POM/filler (yellow) boundary lubrication bearing

Home / Products / HZ-20 boundary lubricated bearings / HZ2Y Porous sintered copper POM/filler (yellow) boundary lubrication bearing
HZ2Y Porous sintered copper POM/filler (yellow) boundary lubrication bearing

HZ2Y Porous sintered copper POM/filler (yellow) boundary lubrication bearing

Application Characteristics

Low friction coefficient and wear rate under grease lubrication conditions

The sliding layer can be equipped with oil holes or grooves to achieve regular grease-filling

Suitable for swinging and rotating movements under heavy loads and low speeds

No water absorption or oil absorption, size stability

Sliding layer thickness of 0.3~0.5 can be precision machined to improve accuracy

The filler does not contain Pb and meets environmental requirements

Applied to axles, brakes, and suspension systems of commercial trucks, as well as textile machinery, printing and dyeing machinery, logistics machinery, etc

Low carbon steel+porous sintered copper+POM/filler (yellow)

Technical Parameter

Characteristic indicators

Unit

Maximum dynamic load

Mpa

70

Maximum static load

Mpa

140

Operation temperature

-40~+120

Maximum linear speed

m/s

2.5

Maximum PV value

m/s·Mpa

2.8

Friction coefficient

0.06~0.12
